Knightsbridge Downlight, Odan Single Tilt Round Trimless
SKU:
OAA1TRW
Brand:
Knightsbridge
Available to Order
📦 Typically 3-4 days delivery
Key Features
✓ Dimmable for adjustable lighti...
✓ Ingress protection rated IP20
Pricing
Special price applied
£14.42
£17.30 Inc VAT
My Scraps
Stock Availability
i
Pickup ordering is available at checkout via Click &
Collect.
📞 Please contact us for current stock availability
Stock levels are updated regularly
📝 Product Description
Odan Single Tilt Round Trimless Downlight White
📋 Detailed Information
Odan Single Tilt Round Trimless Downlight White
All electrical products should be installed by qualified personnel in accordance with current regulations.
⚡ Key Features
- ✓ Dimmable for adjustable lighting control
- ✓ Ingress protection rated IP20
- ✓ Energy efficient 10 W consumption
- ✓ 5 Years manufacturer warranty
- ✓ Recessed mounting for clean ceiling appearance
- ✓ Die Cast Aluminium construction with White finish
📋 Technical Specifications
Technical Document 5
https://www.luckinslive.com/data/4b97aa58-21e5-45b0-9a06-5a40276bec34/df2a796b-2c2f-4ef3-8e45-2f624f2a3722.PDF
Category
Downlights
SKU
OAA1TRW
Product
Luminaire
Type
Downlight
Lamp Base
GU10
Face Shape
Circular
Mounting Position
Ceiling
Mounting Type
Recessed
Adjustability
Adjustable
Fire Rated
N
Dimmable
Y
Corrosion Resistant
N
Vandal Resistant
N
Microwave Sensor Included
N
Photocell Included
N
PIR Included
N
Cover Included
N
Ballast/Starter Included
N
LED Driver Included?
N
Lamp(s) Included?
N
Number of Lamps
1
Wattage
10 W
Ingress Protection
IP20
Emergency
N
Self Contained
N
Housing Material
Die Cast Aluminium
Bezel/Trim Colour
White
Overall Diameter
94 mm
Cut Out Diameter
106 mm
Recess Depth
38 mm
Depth
2 mm
Voltage
230 V
CE Approved
Y
UKCA Approved
Y
Warranty
5 Years
Dimensions
94x38x106mm
Finish
White
Unit Weight
0.225 kg
